Camera

• Image Sensor8 MP CMOS

• Signal SystemPAL/NTSC

• Frame Rate
  USB 3.0:
  MJPEG:
  3840 × 2160 @ 30 fps/25 fps
  1920 × 1080 @ 30 fps/25 fps
  1280 × 720 @ 30 fps/25 fps
  640 × 480 @ 30 fps(default)/25 fps
  YUV:
  1920 × 1080 @ 30 fps/25 fps
  1280 × 720 @ 30 fps/25 fps
  640 × 480 @ 30 fps/25 fps
  USB 2.0:
  MJPEG:
  1920 × 1080 @ 30 fps/25 fps
  1280 × 720 @ 30 fps/25 fps
  640 × 480 @ 30 fps(default)/25 fps
  YUV:
  1920 × 1080 @ 5 fps
  1280 × 720 @ 10 fps/5 fps
  640 × 480 @ 30 fps/25 fps

• Resolution3840 (H) × 2160 (V)

• Min. Illumination0.1 Lux @ (F1.2, AGC ON)

• Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s

• Lens3.6 mm fixed focal lens

• Field of Viewhorizontal FOV: 79°, vertical FOV: 43°, diagonal FOV: 92°

• Lens MountM16

• Day & Night24/7 Color Imaging

• Angle Adjustmentpan: 0°; tilt: -10° to 30°; ratation: 0°

• Cable Length2 m

• Depth of Field2 m to ∿/span>

Audio

• Audio Sampling Rate48 kHz

• Interface

• Video OutputUSB 3.0
• Audio InBuilt-in mic

Operating System

• Recommended systems
  Windows 7/8/10/11 (resolution higher than 1080P is only available in Windows 8.1 and above version)
  Android 8.1 and above version
  Linux 4.14 and above version
  macOS 10.12 and above version
  Chrome OS

General

• Operating Conditions-10°C to 45°C, Humidity: 90% or less (non-condensing)

• Power SupplyDC 5V ± 5% (USB)

• ConsumptionMax. 2.2 W

• Dimension130 mm × 53.2 mm × 56.6 mm (5.12" × 2.09" × 2.23")

• Approx. 137 g (0.30 lb)

• Accessory

• Packing List
  Camera × 1
  USB cable × 1
  Quick Start Guide × 1

• Image Sensor8 MP CMOS

• Signal SystemPAL/NTSC

• Frame Rate
  USB 3.0:
  MJPEG:
  3840 × 2160 @ 30 fps/25 fps
  1920 × 1080 @ 30 fps/25 fps
  1280 × 720 @ 30 fps/25 fps
  640 × 480 @ 30 fps(default)/25 fps
  YUV:
  1920 × 1080 @ 30 fps/25 fps
  1280 × 720 @ 30 fps/25 fps
  640 × 480 @ 30 fps/25 fps
  USB 2.0:
  MJPEG:
  1920 × 1080 @ 30 fps/25 fps
  1280 × 720 @ 30 fps/25 fps
  640 × 480 @ 30 fps(default)/25 fps
  YUV:
  1920 × 1080 @ 5 fps
  1280 × 720 @ 10 fps/5 fps
  640 × 480 @ 30 fps/25 fps

• Resolution3840 (H) × 2160 (V)

• Min. Illumination0.1 Lux @ (F1.2, AGC ON)

• Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s

• Lens3.6 mm fixed focal lens

• Field of Viewhorizontal FOV: 79°, vertical FOV: 43°, diagonal FOV: 92°

• Lens MountM16

• Day & Night24/7 Color Imaging

• Angle Adjustmentpan: 0°; tilt: -10° to 30°; ratation: 0°

• Cable Length2 m

• Depth of Field2 m to ∿/span>

• Audio Sampling Rate48 kHz

• Video OutputUSB 3.0

• Audio InBuilt-in mic

Operating System

• Recommended systems
  Windows 7/8/10/11 (resolution higher than 1080P is only available in Windows 8.1 and above version)
  Android 8.1 and above version
  Linux 4.14 and above version
  macOS 10.12 and above version
  Chrome OS

• Operating Conditions-10°C to 45°C, Humidity: 90% or less (non-condensing)

• Power SupplyDC 5V ± 5% (USB)

• ConsumptionMax. 2.2 W

• Dimension130 mm × 53.2 mm × 56.6 mm (5.12" × 2.09" × 2.23")

• Approx. 137 g (0.30 lb)

Packing List

• Camera × 1
• USB cable × 1
• Quick Start Guide × 1
