Specifications

Model

CS-H3-R100-1J3WKFL

General

Dimensions

75.5 × 75.5 × 155 mm (2.97 × 2.97 × 6.10 inch)

Package Dimensions

227 × 100 × 92 mm (8.94 × 3.94 × 3.62 inch)

Weight

Net weight: 438 g (15.45 oz) With package: 676 g (23.84 oz)

IP Grade

IP67

Operating Conditions

-30 °C ~ 60 ºC (-22 °F ~ 140 °F ) Humidity 95% or less (non-condensing)

Camera

Image Sensor

1/2.7”Progressive Scan CMOS

Shutter Speed

Self-adaptive shutter

Lens

2.8mm @ F2.0, viewing angle: 122° (Diagonal), 106° (Horizontal), 56° (Vertical) 4mm @ F2.0, viewing angle:102° (Diagonal), 86° (Horizontal), 44° (Vertical)

Minimum Illumination

0.01 lux @ (F2.0, AGC ON), 0 Lux with IR

Lens Mount

M12

Day / Night Switch

IR-Cut filter with auto-switching

DNR

3D DNR

WDR

Digital WDR

BLC

Supports

IR Night Vision Distance

Up to 98 ft / 30 m

Video & Audio

Max. Resolution

2304 × 1296 pixels

Frame Rate

Max: 30fps; Self-Adaptive during network transmission

Video Compression

H.265 / H.264

Video Bit Rate

Quad HD; Full HD; HD; Standard. Adaptive bit rate.

Audio Bit Rate

Self-Adaptive

Max. Bitrate

3 Mbps

Network

Wi-Fi Standard

IEEE802.11b, 802.11g, 802.11n

Frequency Range

2.4 GHz ~ 2.4835 GHz

Channel Bandwidth

Supports 20 MHz

Security

64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK

Transmission Rate

11b: 11 Mbps, 11g: 54 Mbps, 11n: 150 Mbps

Wi-Fi Pairing

AP Pairing

Protocol

EZVIZ Cloud Proprietary Protocol

Interface Protocol

EZVIZ Cloud Proprietary Protocol

Wired Network

RJ45 × 1 (10M / 100M Adaptive Ethernet Port)

Function

Detection

AI-Powered Human / Vehicle Shape Detection, Motion Detection

Customized Alert Area

Supports

Integration

Works with Alexa, Google Assistant, IFTTT

General Function

Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark

Storage

Local Storage

Supports microSD card (Up to 512 GB)

Cloud Storage

Supports EZVIZ CloudPlay storage (Subscription required)

Power

Wiring

Hard-Wired

Power Supply

DC 12V / 1A

Power Consumption

Max. 7W

In the box

In the box

- EZVIZ H3 2K Camera

- Drill Template

- Screw Kit

- Waterproof Kit

- Power Adapter

- Regulatory Information

- Quick Start Quide

Certifications

Certifications

CE / FCC / UKCA / UL / WEEE / RoHS / REACH
