Camera

• Image Sensor1/1.8" 3K CMOS
• Signal SystemPAL/NTSC
• Max. Resolution2960 (H) × 1665 (V)
• Min. Illumination0.0003 Lux @ (F1.0, AGC ON), 0 Lux with white light
• Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
• Light AlarmSolid Light Alarm (White Light)
• Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°

Lens

• Lens Type2.8 mm and 3.6 mm fixed focal lens
• Focal Length & FOV

  2.8 mm, horizontal FOV: 112°, vertical FOV: 60°, diagonal FOV: 133°

  3.6 mm, horizontal FOV: 95°, vertical FOV: 50°, diagonal FOV: 115°

• Lens MountM16


• Frame Rate3K@20fps, 4MP@25fps/30fps, 1080p@25fps/30fps
• Wide Dynamic Range (WDR)≥130 dB
• White LightAuto/Off
• Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
• AGCYes
• Day/Night ModeColor
• White BalanceAuto/Outdoor/Global/Manual
• Image EnhancementWDR;Global;HLC;BLC;HLS
• Privacy Mask4 programmable privacy masks
• Noise Reduction3D DNR/2D DNR
• Image SettingsBrightness;Contrast;Mirror;Smart Light;Anti-Banding

Interface

• Video Output1 HD analog output

Event

• Motion Detection4 programmable motion areas

General

• LanguageEnglish
• Operating Condition-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
• Power Supply

  12 VDC ± 25%

  *You are recommended to use one power adapter for one camera, and use 2-pin power supply for long-distance power supply.

• ConsumptionMax. 4 W
• MaterialMetal
• White Light RangeUp to 20 m
• CommunicationHIKVISION-C
• Dimension161.1 mm × 70 mm × 70 mm (6.34" × 2.76" × 2.76")
• WeightApprox. 400 g (0.88 lb.)

Approval

• ProtectionIP67
