Camera

• Image Sensor4K CMOS
• Max. Resolution3840 (H) × 2160 (V)
• Min. Illumination0.01 Lux @ (F1.6, AGC ON), 0 Lux with IR
• Shutter TimePAL: 1/12.5 s to 1/50, 000 s NTSC: 1/15 s to 1/50, 000 s
• Day & NightICR
• Angle AdjustmentPan: 0 to 360°, Tilt: 0 to 90°, Rotation: 0 to 360°
• Signal SystemPAL/NTSC

Lens

• Lens Type2.8 mm and 3.6 mm fixed focal lens
• Focal Length & FOV

  2.8 mm, horizontal FOV: 108°, vertical FOV: 59°, diagonal FOV: 127°

  3.6 mm, horizontal FOV: 88°, vertical FOV: 44°, diagonal FOV: 105°

• Lens MountM12

Illuminator

• Supplement Light TypeWhite Light;IR
• Supplement Light Range

  IR : Up to 25 m

  White Light : Up to 20 m


• Image SettingsBrightness, Sharpness, Smart IR
• Frame Rate

  TVI: 8 MP @12.5 fps, 8 MP @15 fps, 4 MP @25 fps, 4 MP @30fps, 2 MP @25 fps, 2 MP @30 fps

  AHD: 8MP@15fps

  CVI: [email protected], 8MP@15fps

  CVBS: PAL/NTSC

• Day/Night ModeAuto/Color/BW (Black and White)
• Wide Dynamic Range (WDR)Digital WDR
• Image EnhancementDWDR/BLC/HLC/Global
• White BalanceAuto/Manual
• AGCYes

Interface

• Video OutputSwitchable TVI/AHD/CVI/CVBS

General

• Power12 VDC ± 25%, 0.4 A, max. 4.8 W,*You are recommended to use one power adapter to supply the power for one camera.
• MaterialPlastic
• Dimension138.8 mm × Ø70 mm (5.46" × Ø2.76")
• WeightApprox. 160 g (0.35 lb.)
• Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
• CommunicationHIKVISION-C
• LanguageEnglish

Approval

• ProtectionIP67
