General

• Rip-cordYes
• CategoryCat.6
• Sheath printingHIKVISION 4PR 23AWG 75°C U/UTP CAT6 VERIFIED TO ANSI/TIA-568-C.2 PVC ****m mm/dd/yyyy Tracing Code-HS
• Reference standardISO/IEC11801, ANSI/TIA-568-C.2, RoHS 2.0
• Fire resistanceNo
• SeparatorYes

Conductor

• MaterialSolid-Bare Copper (99.95%)
• Diameter0.55 ± 0.005 mm, 23 AWG

Insulation

• MaterialHDPE
• Diameter0.98 ± 0.05 mm

Sheath physical properties

• Before aging : Tensile strength ≥ 13.5 Mpa, Elongation ≥ 150%
• Aging period100°C × 24h × 10d
• After aging : Tensile strength ≥ 12.5 Mpa, Elongation ≥ 125%
• Cold bend-20 ± 2°C × 4h, 8 × cable O.D, no visible cracks

Electrical Characteristics(20℃)

• 1.0-250.0 MHz impedance

  100 ± 15 Ω @ ≤ 100 MHz

  100 ± 25 Ω @100-250 MHz

• 1.0-250.0 Mhz delay skew≤ 45 ns/100 m
• DC resistance≤ 9.38 Ω/100 m
• DC conductor resistance unbalance≤ 5.0%
• Package dimension400 mm (W) × 400 mm (H) × 240 mm (D) (15.75" × 15.75" × 9.45")
• Weight12.3 ± 0.5kg
• Cable length(305 ± 1.5) m
• Ambient temperature-20°C to 75°C (-4°F to 167°F)
• Operating voltage60 V

Sheath

• Thickness0.50 ± 0.10 mm
• MaterialPVC
• ColorOrange
• Diameter6.00 ± 0.30 mm
