General

• Working Temperature-30°C to 65°C (-22°F to 149°F)
• Working Humidity10% to 90% (No Condensing)
• Operation SystemLinux
• Working CurrentMax. 500 mA
• Power Supply12 VDC
• LED IndicatorPower/ Communication
• Processor32 Bit High-performance Processor
• LCD Screen320 × 240 (pixel) LCD-TFT Display Screen
• Communication ModeTCP/IP and Wi-Fi
• Storage256M Storage
• Card Capability100,000 Cards and 300,000 Swiping Card Records
• Input InterfaceDoorbell × 1, Tamper Alarm × 1, Exit Button × 1, Door Magnetic Sensor × 1, Alarm Input × 2
• Output InterfaceLock Relay × 1, Alarm Output × 1
• USB InterfaceUSB 2.0
• Key Board17 Keys
• PromptBeeper and Audio
• Weight280g
• Dimension137mm × 142mm × 35mm (5.4” × 5.6” × 1.4”)
