Display parameters

• Size/
• Operation methodPhysical button
• Type/

Video parameters

• Supplement light : IR supplement



Lens1

• FOVHorizontal 180°, vertical 96°
• PixelMain stream: 1920 × 1080, (720p configurable)͖; sub stream: 720 × 480

Audio parameters

• Audio qualityNoise suppression and echo cancellation

Capacity

• Sub door station capacity16

Network parameters

• Communication protocol : TCP/IP, RTSP
• Wired networkTwo-wire transmission
• Wi-Fi/
• Bluetooth/
• Device interfaces
• Network interface0
• Exit button2
• Lock control2
• Door contact input2
• Power interface1

General

• Button1
• InstallationWall mounting
• Indicator0
• Weight/
• Protective levelIP65
• Power supply method : 24 VDC two-wire power supply (< 16 W) or 12 VDC independent power supply (
• Working temperature-40 °C to 60 °C (-40 °F to 140 °F)
• Working humidity10% to 95%
• Dimensions : 98 mm × 99.8 mm × 43.9 mm (3.86" × 3.93" × 1.73")
• Battery/
• Application environmentOutdoor
• Power consumption4 W
• LanguageEnglish, French, Portuguese (Brazil), Spanish, Russian, German, Italian, Polish, Arabic, Turkish, Vietnamese, Hungarian, Dutch, Romanian, Czech, Bulgarian, Ukrainian, Croatian, Serbian, Portuguese, Slovak
