Model Parameters

Model

CS-CV248-A0-32WFR

Camera

Image Sensor

2 Megapixel 1/3” Progressive Scan CMOS

Shutter Speed

Self-adaptive shutter

Lens

4mm@ F2.2, Diagonal angle: 95°

PT Angle

Pan: 340°, Tilt: 90°

Lens Mount

M12

Day & Night

IR-cut filter with auto-switching

DNR

3D DNR

WDR

Digital WDR

Compression

Video Compression

H.264

H.264 Type

Main profile

Video Bit Rate

HD, Balanced and Smooth. Adaptive bit rate


Max. Resolution

1920×1080

Image setting

Brightness, contrast, saturation, etc. (configurable via EZVIZ Studio)

BLC

Support

Network

Storage

Support Micro SD card (Max. 128G)

Smart Alarm

Motion detection

Wi-Fi Pairing

SmartConfig (Wi-Fi One-Key Configuration)/AP paring

Protocol

EZVIZ cloud proprietary protocol

Interface Protocol

EZVIZ cloud proprietary protocol

General Features

Anti-Flicker, Dual-Stream, Heartbeat Messages, Mirror Image, Password Protection, Watermark

Minimum Network Requirements

2Mbps

Wi-Fi

Standard

IEEE802.11b, 802.11g, 802.11n

Frequency Range

2.4 GHz ~ 2.4835 GHz

Channel Bandwidth

Supports 20MHz

Security

64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS

Transmission Rate

11b: 11Mbps, 11g: 54Mbps, 11n: 135Mbps

General

Operating Conditions

-10°C ~ 55°C, Humidity 95% or less (non-condensing)

Power Supply

DC 5V±10%

Power Consumption

Max. 8W

IR Range

Max. 10 Meters

Product Dimensions

100mm x 100mm x 90mm

Packaging Dimensions

126mm x 126mm x 155mm

Weight

220g
