General

• Power Supply12V DC
• Working Temperature-20°C to +65°C (-4°F to +149°F)
• Working Humidity10% to 90% (Non Condensing)
• Working Current≤500mA
• Reading Frequency125KHz
• Reading Range≤50mm (≤1.97")
• ID Settingsvia DIP Switch
• Audio AlertBeeper
• Power Consumption≤2W
• KeypadNo Keypad (DS-K1102E/M)Keypad with 12 Keys (0 to 9, *, #) (DS-K1102EK/MK)
• CertificationsFCC, CE
• LED IndicatorPower Indicator; Status LED Indicator
• Protection LevelIP 64
• Dimensions121mm × 86.5mm × 14mm (4.76” × 3.41” × 0.55")
• Weight≤0.14Kg
• Installing MethodApplied for 86 & 120 Gang Box

system parameters

• Processor32-bit
