Specifications

Model

CS-BM1 (1080P)

Camera

Image Sensor

1/2.8” 2-Megapixel Progressive Scan CMOS Sensor

Minimum Illumination

0.1 lux

Lens

4 mm @ F1.6, viewing angle: 100° (Diagonal) , 85° (Horizontal), 46° (Vertical)

Day & Night

IR-cut filter with auto-switching

DNR

3D DNR

Night Vision

Up to 5 m / 16 ft

Video & Audio

Max Resolution

1920 x 1080

Frame Rate

15fps. Self-Adaptive during Network Transmission

Video Compression

H.265 / H.264

Video Bit Rate

Full HD; Hi-Def; Standard. Adaptive Bit Rate.

Audio Bit Rate

Self-adaptive

Max. Bitrate

1 Mbps

Function

Detection

Crying Detection, Out-of-Crib (Baby Leaving), Detection Baby Activity (Smart Human) Detection

Smart Alarm

Supports

Two-way Talk

Supports

Auto-play Music

Supports

Network

Wi-Fi Standard

IEEE802.11b, 802.11g, 802.11n

Frequency Range

2.4 GHz ~ 2.4835 GHz

Channel Bandwidth

Supports 20 MHz

Security

64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK

Transmission Rate

11b: 11 Mbps, 11g: 54 Mbps, 11n: 150 Mbps

Wi-Fi Pairing

AP pairing

Protocol

EZVIZ cloud proprietary protocol

Interface Protocol

EZVIZ cloud proprietary protocol

Minimum Network Requirement

2 Mbps

Storage

Local Storage

Supports microSD card (Up to 256 GB)

Cloud Storage

Supports EZVIZ CloudPlay storage (Subscription required)

General

Operating Conditions

-10 °C to 45 °C (14 °F to 113 °F ), humidity 95% or less (Non-condensing)

Power Supply

DC 5V / 2A （Power adaptor purchased separately)

Battery Capacity

2000 mAh

Packaging Dimensions

225 × 127 × 65 mm (8.86 × 5.00 × 2.56 inch)

Dimensions

Rabbit Version: 249 × 50 × 67 mm (9.80 × 1.97 × 2.64 inch) Bear Version: 240 × 50 × 67 mm (9.44 × 1.97 × 2.64 inch)

Net Weight

Rabbit Version: 222 g (7.83 oz) Bear Version: 221 g (7.80 oz)

Certifications

Certifications

CE / FCC / UL / WEEE / RoHS / REACH / UKCA
